In the pipeline system, elbow is a pipe fitting that changes the direction of the pipeline. According to the angle, there are three most commonly used elbows: 45 ° and 90 ° 180 °. In addition, according to the needs of the project, there are other abnormal angle elbows such as 60 °.
Product Introduction
In the pipeline system, elbow is a pipe fitting that changes the direction of the pipeline. According to the angle, there are three most commonly used elbows: 45 ° and 90 ° 180 °. In addition, according to the needs of the project, there are other abnormal angle elbows such as 60 °. Elbow materials include cast iron, stainless steel, alloy steel, malleable cast iron, carbon steel, non-ferrous metals and plastics.
The ways to connect with the pipe include: direct welding (the most commonly used way), flange connection, hot-melt connection, electric fusion connection, threaded connection and socket connection, etc. According to the production process, it can be divided into: welding elbow, stamping elbow, pushing elbow, casting elbow, butt welding elbow, etc. Other names: 90 degree elbow, right angle bend, etc.
Specaification
| Material | CARBON STEEL /ALLOY STEEL A335 P91 P22 P11 |
| Size | Size 1/4" to 64" Outside Diameter 13.7 mm to 1620 mm |
| Standard | ASTM/ANSI.B16.9 ASTM/ANSI B16.28 ASTM /ANSI B16.11 ASTM/ANSI B16.25 BS1965 BS1640DIN 2605 DIN2615 DIN2616 DIN2617 GB 12459-90 |
| Certificates | API5L, ISO 9001:2008,CCIC |
| Wall thickness | SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH80, SCH100 SCH120, SCH160, XS, XXS |
| Surface Treatment | black paint, varnish, oil, galvanized, anti corrosion coatings |
| Marking | wooden case & pallet |
| Pipe Ends | Under 2 inch plain end. 2 inch and above Beveled. Plastic caps (small OD) ,Iron protector (large OD) |
| Pipe Length | 1. Single Random Length and double Random Length.2. SRL:3M-5.8M DRL:10-11.8M or As clients requested length |
| Packaging | Loose package; Packaged in bundles(2Ton Max); bundled pipes with two slings at the both end for easy loading and discharging; End |
| Test | Chemical Component Analysis, Mechanical Properties, Technical Properties, Exterior Size Inspection, hydraulic testing , X-ray |
| Application | liquid delivery; Structure pipe; High and low pressure Boiler tube; Seamless steel tubes for petroleum cracking; oil pipe; gas |
